These heavy-duty cables are often used on adjustable sway bars, but they also work very well as shifter cables. Their operation is so smooth, some of our customers even use them as throttle cables. The 5" minimum bend radius lets them fit tight installations. These cables have a working load rating of 60 pounds in compression and 120 pounds in tension. The stainless steel inner core makes them suitable for marine use.
This "4 Series" version has 1/4-28 UNF male threads at each cable end (our standard Part No. 3460 "3 Series" cables have 10-32 UNF threads). Both ends of the housing are grooved (0.406" / 10.3mm OD) for easy clip-in attachment. All lengths have 3 inches of travel.
Length is measured from end-to-end of the inner cable including the threaded ends.
| Standard Dimensions for Push-Pull Cables |
|---|
| Thread | 1/4-28 (SAE UNF), 1" long |
Housing Groove
to Cable End (min) | 5.56" |
Housing Groove
to Cable End (max) | 8.56" |
| Travel | 3" |
Jacket Length
(Groove to Groove) | End-to-End Length
Minus 14 1/8" |
| All dimensions are +/- 1/4" |
These cables are rated for operating temperatures up to 225° F (107° C). If your application will exceed this limit, you will need to insulate your cable with one of our insulation products such as Aeroquip Fire Sleeve (Part No. 3299-.44) or Thermo-Tec Thermo-Sleeve (Part No. 1835-125).
